Watt -[KRIPOWER]

The KRP-100 series from KRITSNAM (also known as Kripower) is a line of enclosed battery backup SMPS units designed to provide continuous power to a load and charge a connected battery simultaneously. The specific model mentioned, the

, is a 12V output variant.

• Functionality: This unit acts as both a power supply and a battery charger, working like a UPS for connected devices like CCTV and access control systems.
• Zero Transfer Time: Upon mains failure, the battery is automatically connected to the load with zero transfer time, ensuring uninterrupted power supply.
• Output Specifications: The unit provides around 80 Watts of power to the load when on mains and delivers 12V 6A output.
• Charging Capability: It maintains the battery in a fully charged condition using constant current charging of 1.5 Amps.
• Input Voltage: It functions from a wide AC input range. The 12V 6A model (

  KRP-BB-100-XX

  ) accepts an input of 190-280VAC.

• Protection Features: The system includes a host of protection features, such as overload protection, short circuit protection, input under-voltage, and battery reverse polarity protection.
• Deep Discharge Prevention: The unit automatically disconnects the battery from the load if the battery voltage falls below a deep discharge level, protecting the battery's lifespan.
• Indicators: It features LED indicators for "Load on Mains," "Load on Battery," and "Battery Reverse".

•  This is a 12V 100AH battery that can be used with the system.
• 100-12

  : This is a 12V 100AH sealed colloidal battery option suitable for UPS and power systems.
